Genius

The Genius cladding systems have evolved following many years of research and development by specialists within the industry. This A1 fire rated cladding can be used on new builds and in refurbishments or re-clads of existing buildings.

Genius cladding is an aluminium rainscreen cladding system that adheres to the highest possible quality standards and UK building regulations. Alongside having an A1 and A2-s1, d0 fire certification, the system is CWCT tested for air leakage, dynamic pressure and water penetration and impact.

Genius metal cladding is available in 11 ranges, all with their own individual benefits and design features. Read about these below.

Available ranges

The Genius Prime system consists of 3mm aluminium panels which are installed in a unique ‘hook on’ method. This system is available with fully concealed fixings, or with fixings that can be discreetly hidden in the recessed joints.

Key features:

A1 or A2-s1, d0 non combustible
Panels available in large formats
Quick installation times due to the ‘hook on’ method
Recyclable
4.5m2 coverage by one panel

The Genius Secret system consists of folded aluminium panels that utilise fully concealed fixings, making the system ideal for clients looking to create a smooth and continuous facade.

Key features:

A1 or A2-s1, d0 non combustible
Quick and easy installation
Cost effective
Wide range of colours available in PPC or anodised
Secret fixings
Recyclable

Manufactured using CNC machine technology, the Genius Discreet system is a ventilated rainscreen facade. The semi-visible fixing mechanism allows for quick installation and easy removal of single panels.

Key features:

A1 or A2-s1, d0 non combustible
Discrete fixings
Cost effective
Wide range of colours available
Recyclable

Genius Edge is a lightweight rainscreen system available in 2mm and 3mm thicknesses. This system utilises an overlapping fixing method which means that fixings are concealed within the recessed panel joint. Genius Edge can be installed both vertically and horizontally and is available in a wide range of colours in either a PPC, anodised or pre-coated finish.

Key features:

A1 or A2-s1, d0 non combustible
Cost effective
Lightweight
Wide range of colours and finishes available
Concealed fixings
Can be installed vertically or horizontally

Genius Planar is a precise and durable facade system available in 190mm, 225mm and 290mm panel heights, with maximum lengths of up to 6,000mm. This system is ideal for facades where the replication of terracotta or timber is required.

Key features:

A1 or A2-s1, d0 non combustible
Extensive range of designs available
Wide range of colour options
Bespoke panel heights available (subject to minimum order quantities)
Recyclable
Easy to install
Secret fixings
Can be installed horizontally or vertically

The Bespoke Planar system offers all the benefits of the Planar system, with additional customisation options available to create a uniquely profiled or curved edge. Panels are available in standard heights of 190mm and lengths of up to 6,000mm. The panels can be supplied in a wide range of RAL colours, along with anodised, mineral, terracotta, timber and etched finishes.

Key features:

A1 or A2-s1, d0 non combustible
Bespoke panel heights available (subject to minimum order quantities)
Recyclable
Easy to install
Wide range of colours and finishes
Secret fixings
Can be installed either horizontally or vertically

The Genius Flat system offers designers a cost effective with colour matched fixings. Available in 3mm aluminium, this system can be manufactured in a wide range of colours.

This system is also available with digital image perforations on the face of the sheets, creating a truly unique facade from photographs or designs.

Key features:

A1 or A2-s1, d0 non combustible
Recyclable
Easy to install
Wide colour range available
Colour matched fixings available

The Genius Linear system utilises secret fix panels, which give the illusion of a floating system. Most popularly used to fascia and soffit applications, the system is also available for use on the main facade. These panels are available in most metal materials and finishes, including perforated, anodised and PPC.

Key benefits:

A1 or A2-s1, d0 non combustible
Quick installation
Recyclable
Plank lengths of up to 4,000mm
Panels of different colours can be mixed
Secret fix
Appearance of a traditional standing seam at a fraction of the cost

Genius unitised consists of prefabricated units which are typically one to two storeys high and the width of a facade bay. Due to the panels being clad off site, construction on site is much quicker than a normal facade.

Key benefits:

A1 or A2-s1, d0 non combustible
Prefabricated facade system
Quick installation
Reduced handling and storage
Minimal wastage

Expanded mesh is a popular facade solution where ventilation is required. This cladding system is available in mill, powder coated or anodised finishes.

Key benefits:

A1 or A2-s1, d0 non combustible
Recyclable
Wide range of colours
Bespoke and standard fixing grids

This panel has been designed for use on a range of curtain wall or window systems. Available in a range of thicknesses, this product is fully non-combustible, lightweight and is easy to install.

Key features:
